Analog Signal Conditioner Card



Features
  • Four Independent Channels
  • Low Power
  • Configurable As:
  1. Instrumentation Amplifier
  2. Adjustable Gain Amplifier
  3. Adjustable Offset Amplifier
  4. Differential Line Receiver
  5. Differential Line Driver
  6. First Degree Active Low Pass Filter
  7. Second Degree Active Low Pass Filter
  8. Differential and Common Mode Noise Rejection Filters
  9. Integrator
  • Regulated +5 VDC and -5 VDC Outputs
  • Low Cost
  • Full Documentation and Schematic
  • Prototyping Area
  • Spare Pins on the Connector
  • Components Placed on the Pin Sockets to Ease Replacing Them
  • Small Size, 5.625” x 5.000” (143 mm x 126 mm)
  • Industry Standard Dual OpAmps Used
  • LED Power Indicator



Typical Applications
  • Low Level Signal Conditioning
  • Line Buffering
  • Noise Rejection
  • Low Pass Filtering
  • Transducer Interface
  • Anti-aliasing Filtering
  • Data Acquisition Systems
  • Industrial Process Controls
  • Medical Instrumentation
  • Active Filtering
  • Bridge Amplifier
  • Thermocouple Amplifier
  • RTD Sensor Amplifier
  • Differential Mode to Single Ended Line Driver
  • Single Ended to Differential Mode Line Driver
  • Differential Mode to Differential Mode Line Buffer

Ordering Information

Part No. Description Amount
ASCC Analog Signal Conditioner Card Click to Get a Quote
