Manual Crossed Roller XYZ Axis Positioning Stage
MXYZ25-S

Home >  Manual Stages > Crossed Roller Stages, XYZ Axis

Manual Dual-axis Super Thin Linear Positioning Stage Picture

This manual XYZ positioning stage is made of stainless steel with electroless nickel plating.

The table size is 60 x 60 mm has a body weight of 1.38 kg.

The maximum load of this super thin table is 5 kg.

The movement accuracy is Straightness 5microns ,Vertical yawing 25" and Parallel yawing 15".

Specifications
Part No.. Table
size
Axis Load Capacity
(kg)
Weight
(kg)
Material Surface
finish
Movement accuracy
Straightness Vertical yawing Parallel yawing
 MXYZ60-S 60 by 60 XYZ 5 1.38 SUS 440C Electroless nickel plating 5 μm 25" 15"

Mechanical Drawing

Manual Dual-axis Super Thin Linear Positioning Stage Mechanical Drawing

 Ordering Information

Part No. Description Amount
MXYZ60-S Linear Ball Bearing Stage XYZ Axis 60 x 60 mm Table with Travel 13mm Click to Get a Quote
