Solenoid Commander Card

Similar Solenoid Controller and Driver Products

Pick and Hold Module
Proportional (PWM) Module
Closed Loop Solenoid Position Control Module
Pick and Drop Module
Load On-Off Power Cycling Module
Dual Proportional Valve Controller
Serially Controlled Solenoid Driver
Solenoid Control System
Related Products
Solenoid Controller Card
Power Supplies
Solenoids
Features
  • Plug-and-Play
  • Stand-alone
  • Runs Multiple Devices Simultaneously
  • Quick and Easy to Install
  • Very Compact and Easy to Use
  • Easy Programming Language, No Compiler or Assembler Required
  • Different Modes of Operation:
    1) Host Controlled

Typical Applications
  • Life Cycling
  • Endurance Testing
  • Shock and Vibration Testing




Software
  • Easy System Setup and Evaluation

  • Menu Driven

  • Free Software Included

General Purpose Digital Input / Output

  • UP to 20 Digital Inputs and Outputs

  • Optional Quadrature Signals

General Purpose Analog Input

  • Up to 6 Inputs

  • 10 Bits of Resolution

Communication Interface

  • Serial Interface

The Solenoid Control Module is designed for actuation of electro-mechanical components.

The typical applications of the module is actuation solenoids, electro-magnets, relays, motors, voice coil motors, actuators, valves and other applicable devices.

The compact and stand-alone unit consists of controller,  drivers. It conveniently connects to the serial port of the host computer.

The module may be controlled in different ways;

1) Externally Controlled
In this mode, the external host such as a PC, micro-controller or PLC sends a series of commands to the controller via the RS-232 or USB serial port. The controller processes and performs the incoming commands and responds with proper messages.


The module interfaces to a wide variety of analog and digital transducers to monitor the output process. These include LVDTs, RVDTs, Proximity Sensors, Accelerometers, Optical Encoders, Laser Interferometers, Pressure Sensors and other similar devices.

Ordering Information

Part No. Description Amount
SCC-01 Solenoid Commander Card Click to Get a Quote
