Type |
AX100 - A |
|
M
e
c
h
n
i
c
a
l
s
p
e
c |
Table Size |
100 X 100 mm |
| Range of Travel |
40 mm |
| Travel Guide |
Ball screw Φ8, lead 1 mm |
| Runway |
Cross-roller lead-type |
| Load |
20 Kg [49N] |
| Body Weight |
1.6 Kg |
| Material |
Aluminum Alloy |
| Surface treatment |
Black Anodized |
| Line generating method |
R/L |
|
P
r
e
c
i
s
i
o
n
S
p
e
c |
2-phase
resolution
(pulse) |
Resolution (Full Step / Half Step) |
5 /2.5 micron |
| Micro Stepping(1/5 step) |
1 micron |
| Parallelism |
30 micron |
| Moment Parallelism |
15 micron |
| Movement straightness |
1 micron |
| Maximum speed |
40 mm/sec [5 KHz] |
|
Precision
Grade |
Single-direction positioning precision |
5 micron |
| Reciprocating position precision |
+/- 0.3 micron |
| Black clearance |
0.5 micron |
| Idle Run |
1 micron |
|
Normal
Grade |
Single-direction positioning precision |
12.5 micron |
| Reciprocating position precision |
+/- 0.6 micron |
| Black clearance |
1.5 micron |
| Idle Run |
2 micron |
