Motorized XZ-axis Table

Home > Assorted Motorized Multi-axis Actuators > Low Cost Linear Two-axis XZ Stages

Motorized XZ-axis Table, Range of Travel, 300 mm by 300 mm

This motorized two-axis XZ positioning table is made of aluminum alloy with an elegant black anodized surface.

It provides 300 mm of travel at a maximum speed of 50 mm per second. The drive mechanism is lead screw.

The bench size is 120 X 120 mm.

The maximum load of this stage table is Model Dependent.

This linear stage is also available with a servo motor and optical encoder.

The knob mounted on the motor allows for manual adjustment. This knob may be replaced with an optical encoder for precision position verification.

This stage requires a Motion Controller that can be ordered as a complete plug-and-play system with RS-232, USB, joystick, trackball, and keypad control.

Specifications

Type

XZ140-300

Structure Description

Travel

300 mm

Table Size

120x120 mm

Lead Screw Pitch

4 mm per turn

Travel Guide

High Precision Crossed Roller

Motor

Two-Phase Stepper Motor (1.8 Deg)
Phase Resistance	3.8 Ohm, Bi-directional
Maximum Phase Current	1 Amp
9 pin DB-9 Male Connector
Pin Assignment and Description
1	+5 VDC for the Limit Sensors
2	Positive Limit Switch, Open Collector, Normally Open, Needs Pull up Resistor (1000 OHM)
3	Negative Limit Switch, Open Collector, Normally Open, Needs Pull up Resistor (1000 OHM)
4	Return for+5 VDC
5
6	Motor Phase A+
7	Motor Phase A-
8	Motor Phase B+
9	Motor Phase B-

Main Material

Aluminum Alloy

Surface Treatment

Black Anodized

Load Capacity

Model Dependent

Weight

12.6 kg

Typical Accuracy

Resolution

2 microns with 10 Micro-steps per Step Motor Driver in use

Maximum Speed

50 mm/sec

Repeatability

5 microns

Positional Accuracy

10 microns

Accessories Description

Optical Encoder (-04)

Servo Motor

Stepper Motor Driven Mechanical Drawing

Click to Get the STEP file of XZ140-300.

Ordering Information

Part No.	Description	Amount
XZ140-300	Motorized Linear Two-axis XZ Stage, Travel : 300 mm	Click to Get a Quote
